Light Source
Transmitted light source: 3W LED bulb integrated field diaphragm. Epi-fluorescence light source 3W high brightness LED lamps. Enable selecting monochromatic or dichromatic LED for light source.
Standard Accessories
Fuse tube, power cord, instruction manual, dust cover, power supply for LED lamp, blue filter and styrofoam molded pack.
Trinocular Observation Head
Siedentopf observation head inclined at 30° rotatable at 360°.
Diopter adjustment ring on ocular tube(±5).
Vertical phototube for digital camera.
Inter-pupillary distance from 55mm to 75mm.
Eyepiece
Extra wide field 10X (paired) F.O.V. 22mm.
Objectives (Anti fungus coated) Infinity Plan Achromatic
Infinity Plan 4X
Infinity Plan 10X
Infinity Plan 40X
Infinity Plan 100X
Excitation Filters
B Excitation (460nm-470nm) standard.
G Excitation (520nm-530nm) standard.
Mechanical Body
Co-axial focusing system provided PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING is available on right & left side respectively.
Quintuple reversed angle nosepiece.
The mechanical stage is 210mmX140mm and has co-axial low positioned controls.
Substage Condenser
Abbe condenser N.A.1.25 with adjustable iris diaphragm.
Excitation Filters (Optional)
V Excitation (390nm-400nm) optional.
UV Excitation (360nm-370nm) optional.
